Multi Spring Unbalanced Seal
20-100 mm
Seal Size
Pressure
10 kg/cm²
Speed
20 m/s
Temperature
-20…200°C
Carbon, Silicon, TC
Rotary Face
Silicon, TC, SS, Ceramic
Stationary Seat
Secondary Seal
Viton, NBR, EPDM, Silicon
SS304, SS316, SS316L
Metal Parts
Components
SS Casing, SS Spring, Seal Face, Stationary Seats, Delta Ring, Elastomer U-Cup, Buffer Stationary Packing
Chemical Plant
Oil Refinery
Petroleum
Multi Spring Balanced Seal
Seal Size
20–50 mm
Pressure
10 kg/cm²
Speed
15 m/s
Temperature
-20…200°C
Carbon, Silicon, TC
Rotary Face
Stationary Seat
Silicon, TC, SS
Secondary Seal
Viton, NBR, EPDM, Silicon,PTFE
Metal Parts
SS304, SS316,SS316L
Components
SS Casing, SS Spring, Seal Face, Stationary Seat, Viton O-Ring, S.S. Pin
Â
Chemical Plant
Oil Refinery
Multi Spring Balanced /
Unbalanced Seal
20-120mm
Seal Size
Pressure
10 kg/cm²
Speed
20 m/s
Temperature
-20…250°C
Carbon, Silicon, TC
Rotary Face
Silicon, TC, SS, Ceramic
Stationary Seat
Secondary Seal
PTFE, GFT
SS304, SS316, SS316L
Metal Parts
Components
SS Casing, SS Spring, Seal Face, Stationary Seat, PTFE V-Packing, PTFE Stationary Packing, S.S. Pin, S.S. V-Parts
Chemical Plant
Oil Refinery
Petroleum
Multi Spring Balanced /
Unbalanced Seal
20–120 mm
Seal Size
Pressure
10 kg/cm²
Speed
20 m/s
Temperature
-20…180°C
Carbon, Silicon, TC
Rotary Face
Stationary Seat
Silicon, TC, SS
Secondary Seal
Viton, NBR, EPDM, Silicon
SS304, SS316, SS316L
Metal Parts
Components
SS Casing, SS Spring, Seal Face, Stationary Seat, Viton O-Ring, S.S. Pin
Chemical Plant
Oil Refinery
Multi Spring Reverse Balance Seal
Seal Size
20–100 mm
Pressure
10 kg/cm²
Speed
13 m/s
Temperature
-10…250°C
Carbon, Silicon, TC
Rotary Face
Silicon, TC,SS, Ceramic
Stationary Seat
Secondary Seal
Viton, NBR, EPDM, Silicon,PTFE
SS304, SS316, SS316L
Metal Parts
Components
SS Casing, SS Spring, Seal Face, Stationary Seat, Viton O-Ring, SS Support Ring, SS Lock Ring
Chemical Plant
Oil Refinery
Petrochemical
Multi Spring Balanced Seal
20-100 mm
Seal Size
Pressure
10 kg/cm²
Speed
13 m/s
Temperature
-10…250°C
Carbon, Silicon, TC
Rotary Face
Silicon, TC, SS,Ceramic
Stationary Seat
Secondary Seal
Viton, NBR, EPDM, Silicon,PTFE
Metal Parts
SS304, SS316
Components
SS Casing, SS Spring, Seal Face, Stationary Seat, PTFE O-Ring, PTFE Stationary Packing, SS Support Ring, SS Lock Ring
Chemical Plant
Oil Refinery
Petrochemical
 Multi Spring SealsÂ
Our multi-spring design ensures uniform contact pressure, maintaining stability during high-speed.
Multi Spring Unbalanced Seal
Seal Size
20-150 mm
Pressure
10 kg/cm²
Speed
15 m/s
Temperature
20…200°C
Carbon, Silicon, TC
Rotary Face
Stationary Seat
Silicon, TC, SS
Secondary Seal
Viton, NBR, EPDM, Silicon
SS304, SS316, SS316L
Metal Parts
Components
SS Casing, SS Spring, Seal Face, Stationary Seats, Viton O-Ring, SS Support Ring, SS Lock Ring
Chemical Plant
Oil Refinery
Textile
Multi Spring Unbalanced Seal
20-150 mm
Seal Size
Pressure
10 kg/cm²
Speed
12 m/s
Temperature
20…250°C
Carbon, Silicon, TC
Rotary Face
Stationary Seat
Silicon, TC, SS
Secondary Seal
PTFE
SS304, SS316, SS316L
Metal Parts
Components
SS Casing, SS Spring, Seal Face, Stationary Seat, Stationary PTFE Packing, SS Support Ring, PTFE Wedge, SS Lock Ring
Chemical Plant
Oil Refinery
Multi Spring Balanced Seal
20–175 mm
Seal Size
10 kg/cm²
Pressure
Speed
20 m/s
Temperature
20…220°C
Carbon, Silicon, TC
Rotary Face
Stationary Seat
Silicon, TC, SS, Ceramic
Secondary Seal
Viton, NBR, EPDM, Silicon,PTFE
SS304, SS316, SS316L
Metal Parts
Components
SS Casing, SS Spring, Seal Face, Stationary Seat, Viton O-Ring, SS Support Ring
Chemical Plant
Oil Refinery
Petroleum
Petroleum
